Wagner Titanus Pro-Sens Air Sampling Device
TITANUS PRO•SENS® is a universal air sampling device suitable for a broad range of applications. The high degree of modularity of the device makes it possible to achieve a cost-effective solution customised to suit the specific needs of the customer. An additional price advantage comes with the optional equipping of the device with a second detector module.
The base TITANUS PRO•SENS® unit with 2 detector heads fitted (TITANUS PRO•SENS® 2) can be used for separate zone detection of a room and its equipment, or configured as a double knock tripping system. Each detector is completely separate, with no switching or leak between detection zones.
- Robust & Efficient High-Pressure Light Source (HPLS) Detection Technology
- LOGIC•SENS Fire Pattern Recognition Technology
- Freezer Version Operates in -40Deg to +60DegC with No Heater Boxes Required
- A Powerful & Efficient Aspirator Allowing up to 560m of Pipework
- A BlowFree System for Programmed or Automated On-Demand Pipe Clearing
- Modular Plug-In Detector Heads for a Customised & Cost-Effective Solution & Maintenance
- Dual Detector Ability Allows Separate Monitoring & Reporting of Room & Equipment with One Unit
- Time-Saving Installation & Commissioning Via Plug & Play Setup
- Large Capacity 3-Stage Filters with Selectable 1-15 Micron Ratings
- A Large Range of Fittings, Pipework, and Sampling Points
- XP95 Interfacing to FireFinderTM and LoopSenseTM Fire Control Panels
- FIP Bar Graph Display Module Available & SmartGraphicsHD Display Integration
- Cost-Effective Solutions for Every Application Type
Approvals: AS 7240.20-2012
| TITANUS PRO•SENS® | TITANUS PRO•SENS® 2 | |
| Number of Sensor Modules Fitted | 1 | 2 |
| Max. Number of Sampling Holes | 32 | 64 |
| Max. Total Pipe Length Capable | 300m* | 560m* |
| Weight | 1460 grams | 1560 grams |
| Current – Start-Up Maximum | 300mA | 320mA |
| Current - Quiescent (at 24 VDC) | 200mA | 220mA |
| Current - Alarm (at 24 VDC) | 210mA | 240mA |
| Tapered Pipe Connectors | 1x25mm | 2x25mm |
| Operating Voltage | 24VDC (14-30 VDC) | |
| Detector Dimensions | 200mm W x 292mm H x 113mm D | |
| Housing Colour | RAL 9018, Papyrus White | |
| 7010-1000 | ProSens Base Unit-APID |
| 7010-1010 | ProSens Base Unit-CLI |
| 7010-1020 | ProSens Base Unit- OEM |
| 7010-1100 | ProSens- 40 Base Unit- APID |
| 7010-1110 | ProSens-40 Base Unit- CLI |
| 7010-1120 | ProSens-40 Base Unit- OEM |
